Yard Loader 38 HP
2838 L
Strongest in medium class.
High performance for all your needs.
Technical Details
Yard Loader 2838 L | |
| Engine | 3-cylinder-yanmar-38ps, 28,2 kW (38 HP) |
| Displacement | 1642 ccm |
| Exhaust gas treatment | Yes |
| Cooling | Water cooler, Oil cooler |
| Hydrostatic drive / Pressure | Hydrostat /365 bar |
| Transmission | - |
| Lifting capacity | 2200 kg |
| Standard tires | 7.00-12 AS Profil mit 6-Loch Felge |
| Working hydraulics / Pressure | ca. 51 l/min / 180 bar |
| load machine straight with bucket | 1700 kg |
| Tipping load machine straight pallet forks (tele arm fully in) | 1400 kg |
| Speed in km/h | 18 km/h (2 stage) |
| Battery | 12V-75AH |
| Volume Diesel tank | 50 l |
| Volume Hydraulic oil tank | 45 l |
| Width | 1160 mm |
| Load-over height (tele arm fully out on telescop loaders) | 2554 mm |
| Height | 2240 mm |
| Operating weight | 2070 kg |
| Show More | |
More power for a strong appearance.
Our strongest medium class model. A Yanmar engine produces 38 hp to provide you with enough power in every situation. Stage V emission standard is achieved by a diesel oxidation catalyst (DOC) and a diesel particulate filter (DPF). It provides a significant reduction of air pollution for a clean future. No addition of AdBlue required.
The DPF comes with a 6000 hours maintenance free promise, so no worries here.
The 2838 L is a strong all-round-talent that finishes whatever your workday throws at you.
It lifts up to 1700 kg and is still light enough to be transported on a trailer.
Contact us to find out more about how you can benefit from the strength and abilities of the Thaler 2838. Read More
Standard Features
low front car for better stability
adjustable multi purpose steering
Thaler inch-pedal
Optimized parallel motion
adjustable ergonomic seat
Hydraulic quick hitch
3 LED working lights
DPF maintenance free at least 6000 hrs
Thaler tensile pendulum joint
adjustable steering column
planetary drive
2 steering rams
Major Applications
×
![]()
Yard loader 38 hp compared
 Yard Loader 2438 L |  Yard Loader 2438 S |  Yard Loader 2438 H | Yard Loader 2838 L |  Yard Loader 2230 S |  Yard Loader 2230 H | |
| Engine | 3-cylinder-yanmar-38hp, 28,2 kW (38 HP) | 3-cylinder-yanmar-38ps, 28,2 kW (38 HP) | 3-cylinder-yanmar-38ps, 28,2 kW (38 HP) | 3-cylinder-yanmar-38ps, 28,2 kW (38 HP) | 3-cylinder-yanmar-25HP | 3-cylinder-yanmar-25HP |
| Displacement | 1642 ccm | 1642 ccm | 1642 ccm | 1642 ccm | 1331 ccm | 1331 ccm |
| Exhaust gas treatment | Yes | Yes | Yes | Yes | No | No |
| Cooling | Water cooler, Oil cooler | Water cooler, Oil cooler | Water cooler, Oil cooler | Water cooler, Oil cooler | Water cooler, Oil cooler | Water cooler, Oil cooler |
| Hydrostatic drive / Pressure | Hydrostat /365 bar | Hydrostat /365 bar | Hydrostat /365 bar | Hydrostat /365 bar | Hydrostat /365 bar | Hydrostat /365 bar |
| Transmission | - | - | - | - | axial piston motor - Cardan shaft | axialkolbenmotor-gelenkwelle |
| Lifting capacity | 1700 kg | 1600 kg | 1500 kg | 2200 kg | 1500 kg | 1300 kg |
| Standard tires | 10.0/75-15,3 mit 6-Loch Felge | 10.0/75-15,3 mit 6-Loch Felge | 10.0/75-15,3 mit 6-Loch Felge | 7.00-12 AS Profil mit 6-Loch Felge | 10.0/75-15,3 mit 6-Loch Felge | 10.0/75-15,3 mit 6-Loch Felge |
| Working hydraulics / Pressure | ca. 45 l/min / 180 bar | ca. 45 l/min / 180 bar | ca. 45 l/min / 180 bar | ca. 51 l/min / 180 bar | ca. 38 l/min / 180 bar | ca. 38 l/min / 180 bar |
| load machine straight with bucket | 1500 Kg | 1400 kg | 1200 kg | 1700 kg | 1300kg | 1100 kg |
| Tipping load machine straight pallet forks (tele arm fully in) | 1200 kg | 1100 kg | 1000 kg | 1400 kg | 900 kg | 750 kg |
| Speed in km/h | 18 km/h (2 stage) | 18 km/h (2 stage) | 18 km/h (2 stage) | 18 km/h (2 stage) | 16 km/h (2 stage) | 16 km/h (2 stage) |
| Battery | 12V-75AH | 12V-75AH | 12V-75AH | 12V-75AH | 12V-45AH | 12V-45AH |
| Volume Diesel tank | 45 l | 45 l | 45 l | 50 l | 37 l | 37 l |
| Volume Hydraulic oil tank | 37 l | 37 l | 37 l | 45 l | 35 l | 35 l |
| Width | 1120 mm | 1120 mm | 1120 mm | 1160 mm | 1120 mm | 1120 mm |
| Load-over height (tele arm fully out on telescop loaders) | 1995 mm | 2580 mm | 2710 mm | 2554 mm | 2580 mm | 2710 mm |
| Height | 2240 mm | 2240 mm | 2240 mm | 2240 mm | 2210 mm | 2210 mm |
| Operating weight | 1980 kg | 2030 kg | 2070 kg | 2070 kg | 1820 kg | 1870 kg |
