Yard Loader 19 HP
Fits through every door.
The smallest thaler.
Technical Details
Yard Loader 2220 S | |
| Engine | 3-cylinder-yanmar, 14,6 KW (19HP) |
| Displacement | 900 ccm |
| Exhaust gas treatment | No |
| Cooling | Water cooler, Oil cooler |
| Hydrostatic drive / Pressure | hydrostat with automatic control /230 bar |
| Transmission | 2-oil-motors |
| Lifting capacity | 1500 kg |
| Standard tires | 7.00-12 AS Profil mit 4-Loch Felge |
| Working hydraulics / Pressure | ca. 33 l/min / 180 bar |
| Tipping load machine straight pallet forks (tele arm fully in) | 900 kg |
| Speed in km/h | 11 km/h (1 stage) |
| Battery | 12V-45AH |
| Volume Diesel tank | 37 l |
| Volume Hydraulic oil tank | 36 l |
| Width | 920 mm |
| Load-over height (tele arm fully out on telescop loaders) | 1940 mm |
| Load-over height (tele arm fully in on telescop loaders) | 2080 mm |
| Height | 2160 mm |
| Operating weight | 1560 kg |
| Show More | |
A Gifted Talent
From navigating low barn doors and narrow stables to fitting through tight gates and sharp corners, the Thaler 2220 L is designed to operate wherever space is limited, thanks to its compact dimensions. The 2220 S variant, equipped with a standard front carriage and standard boom, achieves a load-over height of 2.48 meters and can lift up to 1100 kg, making it a truly versatile machine for various applications. In situations where overhead clearance is a concern, the optional patented FOPS-ROPS canopy can be hydraulically lowered by up to 25 cm, allowing the operator to remain seated and fully protected. The 2220 S takes on demanding jobs with ease—whether it’s lifting heavy materials, feeding livestock, or stacking hay and boxes. Its compact size, high stability, and excellent maneuverability make it ideal for confined and restricted workspaces. Tasks that previously required manual effort can now be handled effortlessly. Despite being the smallest model in the range, the 2220 S features the Thaler inch-pedal, enabling slow, controlled movements while maintaining full lifting power. A wide range of customization options is available to adapt the loader to specific operational needs. With a broad selection of attachments—including buckets, pallet forks, mowers, sweepers, and snow ploughs—the Thaler 2220 proves to be a powerful, multi-functional asset.
Read More
Standard Features
Convenient access, No drive shaft hump
Large combined water+oil cooler
Thaler inch-pedal
Optimized parallel motion
Adjustable comfortable seat
Hydraulic quick hitch
Led working light
Easy accessible lubrication points
Thaler tensile pendulum joint
Third hydraulic control circuit
z-kinematic
Major Applications
Yard loader 19 hp compared
 Yard Loader 1220 |  Yard Loader 2220 L | Yard Loader 2220 S |  Yard Loader 2320 L |  Yard Loader 2320 S | |
| Engine | 3-cylinder-yanmar, 14,6 KW (19HP) | 3-cylinder-yanmar, 14,6 KW (19 HP) | 3-cylinder-yanmar, 14,6 KW (19HP) | 3-cylinder-yanmar, 14,6 KW (19HP) | 3-cylinder-yanmar-19HP |
| Displacement | 900 ccm | 900 ccm | 900 ccm | 900 ccm | 900 ccm |
| Exhaust gas treatment | No | No | No | No | No |
| Cooling | Water cooler, Oil cooler | Water cooler, Oil cooler | Water cooler, Oil cooler | Water cooler, Oil cooler | Water cooler, Oil cooler |
| Hydrostatic drive / Pressure | hydrostatic transmission with autmotive control | Hydrostat /230 bar | hydrostat with automatic control /230 bar | hydrostat with automatic control /230 bar | hydrostat with automatic control /230 bar |
| Transmission | 4 wheel hub motors | 2-oil-motors | 2-oil-motors | radial piston motor-cardan shaft | radial piston motor-cardan shaft |
| Lifting capacity | 750 kg | 1500 kg | 1500 kg | 1500 kg | 1500 kg |
| Standard tires | 7.00-12 AS | 7.00-12 AS Profil mit 4-Loch Felge | 7.00-12 AS Profil mit 4-Loch Felge | 7.00-12 AS Profil mit 6-Loch Felge | 7.00-12 AS Profil mit 6-Loch Felge |
| Working hydraulics / Pressure | ca. 33 l/min / 160 bar | ca. 33 l/min / 180 bar | ca. 33 l/min / 180 bar | max. ca. 33 l/min /230 bar | max. ca. 33 l/min /230 bar |
| Tipping load machine straight pallet forks (tele arm fully in) | 600 kg | 1100 kg | 900 kg | 1100 kg | 900 kg |
| Speed in km/h | 16 km/h (1 stage) | 11 km/h (1 stage) | 11 km/h (1 stage) | 15 km/h (1 stage) | 15 km/h (1 stage) |
| Battery | 12V-45AH | 12V-45AH | 12V-45AH | 12V-45AH | 12V-45AH |
| Volume Diesel tank | 25 | 28 l | 37 l | 28 l | 28 l, 37 l |
| Volume Hydraulic oil tank | 25 | 36 l | 36 l | 36 l | 36 l |
| Width | 880 mm | 920 mm | 920 mm | 970 mm | 970 mm |
| Load-over height (tele arm fully out on telescop loaders) | 2080 mm | 1940 mm | 1940 mm | 1940 mm | 2480 mm |
| Load-over height (tele arm fully in on telescop loaders) | 2080 mm | 2080 mm | 2080 mm | 2080 mm | 2080 mm |
| Height | 1999 mm | 2160 mm | 2160 mm | 2160 mm | 2160 mm |
| Operating weight | 1010 kg | 1560 kg | 1560 kg | 1560 kg | 1610 kg |
| Show More | |||||
