5 axis wheel loader 3448 L-5A
With great power comes great maneuverability.
Technical Details
 Wheel loader 3448 H | |
| Engine | 4-cylinder-yanmar-48hp, 35,4 kW (48 HP) |
| Displacement | 2190 ccm |
| Exhaust gas treatment | Yes |
| Cooling | Water cooler, Oil cooler |
| Hydrostatic drive / Pressure | Hydrostat /365 bar |
| Transmission | axialkolbenmotor-gelenkwelle |
| Lifting capacity | 2500 kg |
| Standard tires | 10.0/75-15,3 mit 6-Loch Felge |
| Working hydraulics / Pressure | ca. 51 l/min / 180 bar |
| load machine straight with bucket | 1700 kg |
| Tipping load machine straight pallet forks (tele arm fully in) | 1600 kg |
| Speed in km/h | 20 km/h (2 stage) |
| Battery | 12V-75AH |
| Volume Diesel tank | 50 l |
| Volume Hydraulic oil tank | 40 l |
| Width | 1160 mm |
| Load-over height (tele arm fully out on telescop loaders) | 3110 mm |
| Height | 2270 mm |
| Operating weight | 2730 kg |
| Show More | |
Strong, quick and agile.
GaLaBau in fall 2018
Equitana in spring 2019
Sommet dÓR in fall 2019
Through a unique combination of all-wheel and center-articulation steering this loader lifts the definition of maneuverability to the next level.
If both steering modes are combined the inner turning circle radius is reduced to only 76 cm.
Well, now you can turn on a dime.
A width of 166 cm combined with an oscillating rear axle gives an unmatched amount of stability in this class, even at a full 20° bend of the center articulation joint. Now this is something you won’t find anywhere else.
Get in touch and learn more about how the 3448 L-5A is gonna get your job done – every time. Read More
Standard Features
convenient access, no drive shaft hump
adjustable multi purpose steering
Thaler inch-pedal
Optimized parallel motion
adjustable ergonomic seats
Hydraulic quick hitch
3 LED working lights
lubrication point optimized for easy access
heavy duty Thaler center articulation joint
adjustable steering column
oscillating rear axle - for maximum stability
2 steering rams
all-wheel, front-, crab-, articulated-steer - or combined
maintenance free wet multiple-disc-brake
Major Applications
5-axis-steering loader
 Wheel loader 3448 L |  Wheel loader 3448 S | Wheel loader 3448 H | |
| Engine | 4-cylinder-yanmar-48hp, 35,4 kW (48 HP) | 4-cylinder-yanmar-48hp, 35,4 kW (48 HP) | 4-cylinder-yanmar-48hp, 35,4 kW (48 HP) |
| Displacement | 2190 ccm | 2190 ccm | 2190 ccm |
| Exhaust gas treatment | Yes | Yes | Yes |
| Cooling | Water cooler, Oil cooler | Water cooler, Oil cooler | Water cooler, Oil cooler |
| Hydrostatic drive / Pressure | Hydrostat /365 bar | Hydrostat /365 bar | Hydrostat /365 bar |
| Transmission | axialkolbenmotor-gelenkwelle | axialkolbenmotor-gelenkwelle | axialkolbenmotor-gelenkwelle |
| Lifting capacity | 2900 kg | 2900 kg | 2500 kg |
| Standard tires | 10.0/75-15,3 mit 6-Loch Felge | 10.0/75-15,3 mit 6-Loch Felge | 10.0/75-15,3 mit 6-Loch Felge |
| Working hydraulics / Pressure | ca. 51 l/min / 180 bar | ca. 51 l/min / 180 bar | ca. 51 l/min / 180 bar |
| load machine straight with bucket | 1900 kg | 1800 kg | 1700 kg |
| Tipping load machine straight pallet forks (tele arm fully in) | 1800 kg | 1800 kg | 1600 kg |
| Speed in km/h | 20 km/h (2 stage) | 20 km/h (2 stage) | 20 km/h (2 stage) |
| Battery | 12V-75AH | 12V-75AH | 12V-75AH |
| Volume Diesel tank | 50 l | 50 l | 50 l |
| Volume Hydraulic oil tank | 40 l | 40 l | 40 l |
| Width | 1160 mm | 1160 mm | 1160 mm |
| Load-over height (tele arm fully out on telescop loaders) | 2554 mm | 2930 mm | 3110 mm |
| Height | 2270 mm | 2270 mm | 2270 mm |
| Operating weight | 2650 kg | 2690 kg | 2730 kg |
| Show More | |||
Compatible attachments
Our product supports compatible attachments that enhance functionality and ensure a perfect fit, delivering
seamless performance and easy integration.
Trusted Across Industries
Solutions Made to Fit Every Industry
Agriculture, Construction, Municipality, Gardening, Cattle Farming, Animal Park, Trade & Industry, Timber Industry
Agriculture
Construction
Municipality
Gardening
Cattle Farming
Animal Park
Trade & Industry
Timber Industry
